Industrial Combustion Burners

• Available to <30 ppm NOx without FGR
• ~3% O2 across a wide load range
• Up to 10:1 turndown ratio when firing gas
• Can fire #2 fuel oil as backup fuel

The SBR-30 series burner, capable of less than 30 ppm NOx emissions without FGR, offers natural gas fuel option from 16.8 to 54.6 MMBTU/hr. Burner model sizes range from 400-700 BHP as a traditional jet style burner and 800-1300 BHP with a fan over design.

• 3.4 to 42.0 MMBTU input range
• 80 to 1,000 HP
• Gas and #2-#6 oil, combination, alt. fuels
• Available as LND down to < 30 ppm NOx
• Available as NTD down to < 9 ppm NOx

The D series forced draft design allows for trouble-free and superior efficiency across a wide range of applications.

• 37.8 to 92.4 MMBTU/hr input range
• 900 to 2,200 HP
• Gas, oil, combination
• Available as LNXL down to <30 ppm NOx
• Available as NTXL down to <9 ppm NOx

The XL series burner feature a unique and precise air-metering system which permits accurate air-to-fuel settings for maximum combustion efficiency.

• Available to <5 ppm NOx with FGR
• ~3% O2 across a wide load range
• Up to 6:1 turndown ratio when firing gas
• Dual fuel capability
• Fuel switch over without mechanical adjustments

The SBR-5 series burner, capable of less than 5 ppm NOx emissions with FGR, offers: natural gas fuel option from 10.5 to 42 MMBTU/hr.

The superior burner technology in the SBR-5 gives it a 1% efficiency advantage over competitors as well as ultra-low NOx combustion. The SBR-5 attains <5 ppm NOx with flue gas recirculation (FGR).

• 46.2 to 63.0 MMBTU/hr
• 1,100 to 1,500 HP
• Gas, #2/#6 oil and combination
• Available to <30 PPM NOx

The S1 series burners use a true forced-draft design to deliver rated capacities against a wide range of furnace pressures.

• 2.5 to 63 MMBTU/hr
• 60 to 1,500 HP
• Natural gas or propane
• Low NOx achieved without FGR

The MTH burner is designed for process heating applications such as thermal fluid systems and hot oil heating.

• 1.5 to 92.4 MMBTU/HR input range
• 36 to 2,200 boiler HP
• Gas, #2 oil and combination
• Available to <9 ppm NOx

The NT series is an Ultra-Low NOx performing burner series capable of sub 9ppm NOx without complicated surface combustion mesh. Available as gas only or dual fuel.

• 16.8 to 42.0 MMBTU/hr input range
• 400 to 1,000 BHP
• Gas, #2 oil and combination
• Available to <30 ppm NOx

E series burners provide increased boiler efficiency reducing on/off cycling. Utilizing a low pressure drop firing head design and low blower motor horsepower requirement, it also saves electrical energy.  To maximize your boilers efficiency, the E-burner utilizes dual gas manifold and pressure air oil atomization to ensure high turndown on both fuels.

• 1.4 to 10.5 MMBTU/HR
• Gas, light and heavy oil fuels
• Low-pressure air atomizing system on oil with rotary vane compressor
• Lower gas supply pressure configurations available for New York City requirements
• Full modulation

The Industrial Combustion M series burner forced draft design allows for tried and true trouble-free operation and superior efficiency on boiler, heater, furnace, kiln and dryer applications worldwide.

• 1.3 to 16.8 MMBTU/hr
• 31 to 400 HP
• Gas, oil, and combination
• Available to <30 ppm NOx

The V series burners boast an aerodynamic air-damper design which permits accurate air-to-fuel settings for maximum combustion efficiency.

• 0.375 to 3.8 MMBTU/hr input range
• 9 to 90 HP
• LNQ8 Series for 20 and 30 PPM NOx applications
• Easy setup and commissioning
• Quiet operation
• Small footprint

The Q series burners are designed around efficiency and operational simplicity. This ultra-quiet, compact burner has the high-efficiency and ease of use perfect for almost any commercial application.
